5G communication testing, wireless terminal automated testing
Aerospace communication systems
Precision measurement equipment, radio frequency signal control of radar transmitters
Communication and navigation systems
Optical communication module-related testing
Interconnection of wireless communication base stations
● Wide frequency band, with a maximum operating frequency of 110GHz.
● DPDT switch, which can be used as SPDT.
● Requency coverage: 5.8GHz - 110GHz.
● Low standing wave: ≤ 1.2@(75GHz - 110GHz).
● High isolation: ≥ 70dB@(75GHz - 110GHz).
● Ultra-small size.
| Item | Frequency (GHz) | VSWR | Material | Isolation（dB） | Insert loss（dB） | Flange/Interface | TDS |
|---|---|---|---|---|---|---|---|
| BJ70（WR137） | 5.85～8.2 | 1.15 | Al | 60 | 0.15 | FDP | Download |
| BJ84（WR112） | 7.05～10.0 | 1.15 | Al | 60 | 0.15 | FBP | Download |
| BJ100（WR90） | 8.2～12.4 | 1.15 | Al | 60 | 0.15 | FBP | Download |
| BJ120（WR75） | 10.0~15.0 | 1.15 | Al | 60 | 0.15 | FBP | Download |
| BJ140（WR62） | 12.4~18.0 | 1.15 | Al | 60 | 0.15 | FBP | Download |
| BJ180（WR51） | 15.0~22.0 | 1.15 | Al | 60 | 0.15 | FBP | Download |
| BJ220（WR42） | 18.0~26.5 | 1.15 | Al | 60 | 0.15 | FBP | Download |
| BJ260（WR34） | 22.0~33.0 | 1.15 | Al | 60 | 0.15 | FBP | Download |
