Directional Couplers
● Wide frequency band, high directivity, low loss.
● Max power: 1000W.
● Single directivity, bi-directionality, high-power type, bridge type.
| Classification | Type | Working Frequency (GHz) | Coupling (dB) | Coupling flatness (dB.max) | Ins.Loss (dB.max) | Direction (dB.min) | VSWR (max) | Power （W） | Connector | Download |
|---|---|---|---|---|---|---|---|---|---|---|
| OH1SSF10-1/12 | 1~12 | 10±1 | ±0.7 | 0.9 | 12 | 1.4 | 50 | SMA-F | ||
| OH1SSF20-1/4 | 1~4 | 20±1 | ±0.7 | 0.4 | 20 | 1.2 | 50 | SMA-F | ||
| OH1SSF30-0.5/6 | 0.5~6 | 30±1 | ±1 | 0.6 | 16 | 1.3 | 50 | SMA-F | ||
| OH1SSF10-2/18 | 2~18 | 10±1 | ±1 | 0.8 | 15 | 1.5 | 50 | SMA-F | ||
| OH1SSF20-2/18 | 2~18 | 20±1 | ±1 | 0.7 | 12 | 1.5 | 20 | SMA-F | ||
| OH1SSF30-2/18 | 2~18 | 30±1 | ±1 | 0.7 | 12 | 1.5 | 20 | SMA-F | ||
| OH1SKF10-0.5/26.5 | 0.5~26.5G | 10±0.1 | ±1 | 2.1 | 12 | 1.5 | 20 | 2.92-F | ||
| OH1SKF20-0.5/40 | 0.5~40 | 20±1 | ±1.2 | 2.6 | 10 | 1.7 | 20 | 2.92-F | ||
| OK1SSF30-0.5/18 | 0.5~18 | 30±1 | ±1 | 1.2 | 10 | 1.4 | 30 | SMA-F | ||
| OH1SKF10-1/40 | 1~40 | 10±1 | ±1.2 | 2.2 | 10 | 1.7 | 20 | 2.92-F | ||
| OH1SKF20-1/40 | 1~40 | 20±1 | ±1.2 | 2 | 10 | 1.7 | 20 | 2.92-F | ||
| OH1SKF30-1/40 | 1~40 | 30±1 | ±1.5 | 2 | 10 | 1.7 | 20 | 2.92-F | ||
| OH1DNF30-0.95/1.22 | 0.95~1.22 | 30±1 | ±1 | 0.3 | 20 | 1.25 | 100 | N-F | ||
| OH1DSF20-0.5/18 | 0.5~18 | 20±1 | ±1 | 2.2 | 12 | 1.5 | 30 | SMA-F | ||
| OH1DSF30-6/18 | 6~18 | 30±1 | ±1 | 0.9 | 15 | 1.5 | 30 | SMA-F | ||
| OH1DSF20-0.5/3 | 0.5~3 | 20±1 | ±1 | 0.7 | 18 | 1.3 | 100 | SMA-F | ||
| High power | OH2DL29F50-0.08/1 | 0.08~1 | 50±1 | ±1 | 0.2 | 20 | 1.1 | 3000 | MAin path: L29-F Coupling: SMA-F | Download |
| High power | OH2DNF40-0.08/1 | 0.08~1 | 40±1 | ±1 | 0.2 | 20 | 1.1 | 1000 | MAin path: N-F Coupling: SMA-F | Download |
| High power | OH2DNF40-0.08/1 | 0.08~1 | 40±1 | ±1 | 0.2 | 20 | 1.1 | 5000 | MAin path: N-F Coupling: SMA-F | Download |
| High power | OH2DNF40-1/6 | 1~6 | 40±1.2 | ±1 | 0.3 | 16 | 1.2 | 200 | MAin path: N-F Coupling: SMA-F | Download |
| High power | OH2DNF40-10k/1G | 10K ~1G | 40±0.6 | ±1.2 | 0.6 | 20 | 1.3 | 500 | MAin path: N-F Coupling: SMA-F | Download |
| High power | OH2DNF40-10k/1G-A | 10K ~1G | 40±0.6 | ±1.2 | 0.6 | 20 | 1.3 | 200 | MAin path: N-F Coupling: SMA-F | Download |
| High power | OH2DNF40-10k/500M | 10K ~0.5G | 40±0.5 | ±1 | 0.5 | 20 | 1.2 | 500 | MAin path: N-F Coupling: SMA-F | Download |
| Bridge Coupler | DQ011606 | 0.001~6 | 16±1 | 1 | 2 | 22 | 1.17 | 1 | SMA-F | Download |
| Bridge Coupler | DQ011620 | 0.001~20 | 16±1.5 | 1.5 | 3.2 | 20 | 1.22 | 1 | SMA-F | Download |
| Bridge Coupler | DQ011626 | 0.001~26.5 | 16±1.5 | 2 | 3.5 | 18 | 1.3 | 1 | SMA-F | Download |
| Bridge Coupler | DQ411640 | 0.001~40 | 17±2 | 4 | 4 | 15 | 1.43 | 1 | 2.4-F | Download |
| Bridge Coupler | DQ021606 | 0.001~6 | 16±1 | 1 | 3.5 | 22 | 1.17 | 1 | SMA-F | Download |
| Bridge Coupler | DQ021620 | 0.001~20 | 16±1 | 1.5 | 4.5 | 20 | 1.22 | 1 | SMA-F | Download |
| Bridge Coupler | DQ021626 | 0.001~26.5 | 16±1 | 2 | 5.5 | 18 | 1.38 | 1 | SMA-F | Download |
| Bridge Coupler | DQ421640 | 0.001~40 | 17±2 | 4 | 7 | 12 | 1.67 | 1 | 2.4-F | Download |
| Bridge Coupler | DQ021606YZ | 0.001~6 | 16±1 | ±2 | 4 | 20 | / | 1w/10w | / | Download |
| Bridge Coupler | DQ421740 | 1MHz~40GHz | 16dB ±1.5dB | ±1.5 | 5.5 | 20 | / | 1W/10W | 2.4mm-Female | Download |
